TP-LINK (SG2210MP) JetStream 10-Port Gigabit Smart Switch with 8-Port PoE+, 2 GB SFP Slots, Rackmountable
TP-LINK (SG2210MP) JetStream 10-Port Gigabit Smart Switch with 8-Port PoE+, 2 GB SFP Slots, Rackmountable

TP-LINK (SG2210MP) JetStream 10-Port Gigabit Smart Switch with 8-Port PoE+, 2 GB SFP Slots, Rackmountable

£193.53 inc. VAT

Product details

Description

Specification

  • Rackmountable: Yes
  • Managed: Smart
  • Number of Ports: 10
  • Max RJ45 Transfer Rate: 10/100/1000 Mbps
  • #Hide#Max SFP Transfer Rate: 2.5G SFP
  • Interface(s): “8 x 10/100/1000 Mbps RJ45 Ports, all supporting PoE+ (Auto-Negotiation/Auto MDI/MDIX)
    2 x 100/1000 Mbps SFP Slots”
  • PoE Ports (RJ45): Standard: 802.3at/af compliant
    PoE+ Ports: 8 Ports
    Power Supply: 150 W
  • Standards and Protocols: “IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p”
  • Switching Capacity: 20 Gbps
  • Power Supply: PoE

    Max Consumption:
    12.2 W (110 V / 60 Hz with no PD connected)
    173.9 W (110 V / 60 Hz with 150 W PD connected)

  • Dimensions: 294 x 180 x 44 mm
  • Mac Address Table: 8K
  • Packet Forwarding Rate: 14.9 Mpps
  • Jumbo Frame: 9 KB
  • Additional Features: See Overview
  • Quality of Service: 802.1p CoS/ DSCP priority
    8 priority queues
    Priority Schedule Mode
    Queue Weight Config
    Bandwidth Control
    Smoother Performance
    Actions for flows
    Storm Control
  • Layer Features: DHCP Relay
    DHCP L2 Relay
    Link Aggregation
    Spanning Tree Protocol
    Loopback Detection
    Flow Control
    Mirroring
    Device Link Detect Protocol (DLDP)
    802.1ab LLDP/ LLDP-MED
  • VLAN: VLAN Group
    802.1Q tag VLAN
    MAC VLAN
    Protocol VLAN
    GVRP
    Voice VLAN
  • Access Control: Support up to 230 entries
    Time-Range
    Time-based ACL
    MAC ACL
    IP ACL
    IPv6 ACL
    Combined ACL
    Rule Operation
    Policy Action
    ACL Rules Binding
  • Security: AAA
    802.1X
    IP/IPv6-MAC Binding
    IP Source Gurad
    IPv6 Source Gurad
    DoS Defend
    Static/Dynamic/Permanent Port Security
    Broadcast/Multicast/Unicast Storm Control
    Port Isolation
    Secure web management through HTTPS with SSLv3/TLS1.2
    Secure Command Line Interface management with SSHv1/SSHv2
    IP/Port/MAC based access control
  • Management: “Omada App
    Centralized Management
    Web-based GUI and CLI management
    SNMPv1/v2c/v3
    SNMP Trap/Inform
    RMON (1,2,3,9 groups)
    SDM Template
    DHCP/BOOTP Client
    Dual Image, Dual Configuration
    CPU Monitoring
    Cable Diagnostics
    EEE
    System Log
    802.1ab LLDP/ LLDP-MED”
  • Environment: “Operating Temperature: 0C~40C (32F~104F);
    Storage Temperature: -40C~70C (-40F~158F)
    Operating Humidity: 10%~90% non-condensing
    Storage Humidity: 5%~90% non-condensing”
  • Package Contents: TL-SG2210MP
    Power Cord
    Installation Guide
    Rackmount Kit
    Rubber Feet
  • Package Type: Retail
  • Package Weight: 2.1600 kg
  • Warranty: Limited Lifetime
  • #Hide#POE: Yes

This product is in stock!

Order before 4PM for next working day delivery
SKU: SWI-10TPJETSMARTPOE-GB Category: Tag:

Have Any Questions?

Our experts are ready to help you!

Chat now

Description



JetStream 10-Port Gigabit Smart Switch with 8-Port PoE+


  • 150 W PoE Budget: 8 802.3at/af-compliant PoE+ ports with a total power supply of 150 W*.
  • Full Gigabit Ports: 8 gigabit PoE+ ports and 2 gigabit SFP Slots provide high-speed connections.
  • Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring.
  • Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
  • Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm Control, DHCP Snooping, 802.1X, Radius Authentication, and more.
  • Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.



Software Defined Networking (SDN) with Cloud Access

Omada's Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network-all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.

*PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors.

**Zero-Touch Provisioning requires the use of Omada Cloud-Based Controller.



Additional information

Weight 2.1600 kg
